Fiber Cleaver

Description:

6S high precision fiber cleaver use for precision cutting single fiber tools. This applies to both cutter

250μ m coated fiber also applies to 900μ m coated fiber. Cut more precisely, without any special skills.

Fiber Cutting Length

Φ0.25mm fiber cable:5mm-20mm

Φ0.9mm:10mm-20mm

FTTH fiber cable:5mm-12mm

Feature:

1.With the introduction of the FC-6S,solidity>HV450, Reach up to 80um ,Difficult to scratch
2.Small size, light weight, easy disassembly
3.Typical Cleave Angle: <0.5 Degrees
4.Apply for Single Fiber,FTTH wire cable

Production Parameter:

Name: Fiber Cutter FC-6S

Cutting angle: 0.5 °

Fiber diameter: 125μ m.

Coating Diameter: 0.25mm and 0.9 mm

Dimensions: 63 W × 76D × 63 H  (mm).

Weight: 430 grams

Blade Life: 36,000 core (1000core×12 blade angle × 3 blade height)

Accessories: Blade Model: The Fund's 20BL
